Container Dimensions

What could be the right container type for you? The Containerdetails in an overview container type, container dimensions , container weight, thus you are able to choose the suitable container from your forwarder.



Please notice the following given dimensions are examples and can be vary from forwarding agency to  forwarding agency and their available equipment.!



Containertypes

20' Box Container

Inside Dimensions (LxWxH)

Door Opening (WxH)

Tare

Max. Payload

Capacity

5,89 x 2,35 x 2,39 m

2,34 x 2,29 m

2250 kg

28230 kg

33,2 cbm

20 FT Box Container




40' Box Container

Inside Dimensions (LxWxH)

Door Opening (WxH)

Tare

Max. Payload

Capacity

12,02 x 2,35 x 2,39 m

2,34 x 2,29 m

3780 kg

26700 kg

67,7 cbm

40 FT Box Conatiner




40' High Cube Container

Inside Dimensions (LxWxH)

Door Opening (WxH)

Tare

Max. Payload

Capacity

12,02 x 2,35 x 2,69 m

2,34 x 2,59 m

4020 kg

26460 kg

76,3 cbm

40 FT High Cube Container




20' Open Top Container

Inside Dimensions (LxWxH)

Door Opening (BxH)

Tare

Max. Payload

Capacity

5,89 x 2,35 x 2,37 m

2,33 x 2,28 m

2250 kg

28230 kg

32,0 cbm

20 FT Open Top Container




40' Open Top Container

Inside Dimensions (LxWxH

Door Opening (BxH)

Tare

Max. Payload

Capacity

12,02 x 2,35 x 2,37 m

2,33 x 2,28 m

3850 kg

26740 kg

65,5 cbm

40 FT OT Container




20' Hard Top Container

Inside Dimensions (LxWxH)

Door Opening (WxH)

Tare

Max. Payload

Capacity

5,89 x 2,34 x 2,38 m

2,33 x 2,28 m

2700 kg

27780 kg

32,8 cbm

20 FT Hard Top Container




40' Hard Top Container

Inside Dimensions (LxWxH)

Door Opening (WxH)

Tare

Max. Payload

Capacity

12,02 x 2,35 x 2,38 m

2,34 x 2,29 m

4700 kg

25780 kg

67,2 cbm

40 FT OT Hard Top




40' High Cube Hard Top Container

Inside Dimensions (LxWxH)

Door Opening (WxH)

Tare

Max. Payload

Capacity

12,02 x 2,35 x 2,69 m

2,33 x 2,52 m

4900 kg

25580 kg

75,8 cbm

40 FT High Cube Hard Top Container




20' Flat

Inside Dimensions (LxWxH)

Tare

Max. Payload

5,98 x 2,23 x 2,25 m

2500 kg

27800 kg

20 FT Flat




40' Flat

Inside Dimensions (LxWxH)

Tare

Max. Payload

12,01 x 1,22 x 1,98 m

4200 kg

40800 kg

40 FT Flat




20' Platform

Dimensions (LxW)

Tare

Max. Payload

6,05 x 2,43 m

2520 kg

27960 kg

20 FT Platform





40' Platform

Dimensions

Tare

Max. Payload

12,19 x 2,24 m

5700 kg

39300 kg

40 FT Platform
All technical details without warranty!
