CNC Lathe
Offer
- stock-no.:
- 0300551
- type of machine:
- CNC Lathe
- make:
- BÖHRINGER
- model:
- NG 200
- year of manufacture:
- 2001
- type of control:
- CNC
- country of origin:
- Germany
- freight basis:
- EXW -free on truck
- storage location:
- Leipzig 1
- delivery time:
- immediately
- price:
- on request
technical details
- turning length:
- 850 mm
- swing over bed:
- 600 mm
- x-axis:
- 220 mm
- z-axis:
- 950 mm
- control:
- Siemens 840D
- speeds:
- 0-4500 U/min
- spindle bore:
- 65 mm
- swing diameter:
- 290 mm
- feed:
- y/y: 25 m/min
- rapid traverse:
- x/y: 25 m/min
- tool turret:
- 2 Stück
- work height max.:
- 1200 mm
- spindle hours:
- 25071 h
- total power requirement:
- 60 kVA
- weight of the machine ca.:
- 10,0 t
- dimension machine approx.LxWxH:
- L:4,05xB:3,6xH:2,8 m
- dimension swarf conveyor LxWxH:
- L:5,8xB:1,05xH:2,2 m
additional information
with 2 supports
tailstock NC controlled (cone SK30), shift 740mm, contact pressure force 3000-8000 Nm
steady rest slide NC-controlled
part pick up clamping device hydr. , force operated with 1 power clamping chuck make SMW autoblock
swarf conveyor with coolant device
Sorry the machine has been sold already! Here you will find more machines referring to your required category.
