Center Lathe
Offer
- stock-no.:
- 0303077
- type of machine:
- Center Lathe
- make:
- WEILER
- model:
- C50x2000
- year of manufacture:
- 2006
- type of control:
- conventional
- country of origin:
- Germany
- freight basis:
- EXW, free on truck unpacked
- storage location:
- Leipzig 5
- delivery time:
- immediately
- price:
- on request
technical details
- turning diameter over bed:
- 570 mm
- turning diameter over support:
- 340 mm
- turning length:
- 2000 mm
- swing diameter over bed:
- 570 mm
- centre height:
- 270 mm
- centre distance:
- 2000 mm
- spindle bore:
- 83 mm
- revolution per minute:
- 1 - 2500 / 2step U/min
- max. torque on the spindle:
- 1100 Nm
- longitudinal feeds::
- 0,001 - 50 mm/U
- cross feed:
- 0,001 - 50 mm/U
- tailstock quill adjustment::
- 200 mm
- tailstock quill:
- innen: MK5 mm
- total power requirement:
- 12 Kw (30 kVA) kW
- weight of the machine ca.:
- 3,4 t
- dimension machine approx.LxWxH:
- 3,7 x 2,0 x 1,75 m
